Toshiba TEC CE4M Printhead for UV Printers

Toshiba TEC CE4M Printhead

The Toshiba TEC CE4M printhead is a genuine, brand-new industrial printhead designed for compatible printing systems. It uses multi-drop grayscale piezoelectric technology to deliver variable ink droplets, supporting detailed image reproduction and controlled ink deposition.

Featuring 636 active nozzles and 16 grayscale levels, the Toshiba TEC CE4M printhead supports a drop volume range of 5 pl to 35 pl. Its 53.7 mm print width and four ink inlets make it suitable for compatible industrial printing applications. An integrated water channel helps regulate printhead temperature during operation.

Item Details

Specification	Detail
Brand	Toshiba TEC
Model	CE4M
Printhead Technology	Multi-drop grayscale piezoelectric
Active Nozzles	636
Grayscale Levels	16 levels
Drop Volume Range	5 pl–35 pl
Native Resolution	150 dpi
Maximum Resolution	300 dpi
Print Width	53.7 mm
Firing Frequency	2.8–28 kHz
Ink Inlets	4
Temperature Control	Integrated water channel for temperature regulation
Ink Compatibility	UV-curable and oil-based pigment inks
Supplied Information	Head ID, voltage and waveform information

Application

The Toshiba TEC CE4M printhead is designed for compatible industrial printing systems that use UV-curable or oil-based pigment inks. Its multi-drop grayscale technology and variable 5 pl to 35 pl drop volume support printing applications that require controlled ink deposition and different levels of image detail.

The integrated water channel helps regulate printhead temperature during operation. Before purchasing, confirm that your printer supports the CE4M model and the specified ink system.

Condition

This Toshiba TEC CE4M printhead is 100% genuine original Toshiba TEC and brand new. Head ID, voltage and waveform information are supplied to support printhead identification and system configuration. Please confirm the applicable setup requirements before installation.

Compatibility

The Toshiba TEC CE4M printhead is intended for compatible industrial printing systems that support its electrical interface, drive voltage, waveform requirements and ink configuration. It supports UV-curable and oil-based pigment inks according to the supplied specifications.

Printer compatibility cannot be confirmed by the model name alone. Before ordering, check your existing printhead model and printer specifications. If you need assistance, contact Glowyprint with your printer model and current printhead details for compatibility confirmation.
